Interactive Whiteboards

Interactive Whiteboards

Interactive Whiteboards

Are you satisfied with how communication is done in your business?
Ricoh wants to dramatically change the way you work by providing
communication services brimming with creativity.

baloon
Interactive Whiteboards

Interactive Whiteboards

Are you satisfied with how communication is done in your business? Ricoh wants to dramatically change the way you work by providing communication services brimming with creativity.

Ricoh's high-quality Interactive Whiteboards (IWBs) encourage innovative collaboration anytime, anywhere, and with anyone. You can use IWBs to enable ideas to be shared right away and reduce work to produce meeting minutes, helping to maximize team performance.

Key features

Interactive Whiteboards Line-up
D series

Model name RICOH Interactive
Whiteboard D8600
RICOH Collaboration
Board D7510
RICOH Collaboration
Board D6520
RICOH Collaboration
Board D5530
RICOH Interactive
Whiteboard D3210
Size W2009×H1200.4
×D125.4(mm)
W1733×H1045
×D79(mm)
W1508×H920
×D83(mm)
W1290×H773
×D78(mm)
(Landscape)

W773×H1290
×D78(mm)
(Portrait)
W789×H480
×D70(mm)
Weight 122kg 59kg 45kg 35kg 15kg
Display Resolution 4K 4K 4K 4K FullHD
Contrast
Ratio
1200:1 4000:1 5000:1 4000:1 3000:1
Touch 10points 20points 20points 20points 10points
I/F
USB:
USB 2.0 (TypeA) x 2
 Side access
USB 2.0 (TypeA) x 2
 Bottom access
USB 3.0 (TypeA) x 5*
* 1port for only charging.
USB 3.0 (TypeB)
Video:
HDMI input
Display Port input
VGA input
DVI-D input
Display Port output
Audio:
12W+12W
(Internal Speaker)
3.5mm Stereo input
Speaker output
Control:
RS-232C
input/output
USB:
USB 3.0 (Type-A) x 6
USB 3.0 (Type-B) x 1
Video:
HDMI input
Display Port input
VGA input
Display Port output
Audio:
12W+12W
(Internal Speaker)
3.5mm Stereo input
Headphone OUT output
Control:
RS-232C
input/output
USB:
USB 3.0 (Type-A) x 6
USB 3.0 (Type-B) x 1
Video:
HDMI input
Display Port input
VGA input
Display Port output
Audio:
12W+12W
(Internal Speaker)
3.5mm Stereo input
Headphone OUT output
Control:
RS-232C
input/output
USB:
USB 3.0 (Type-A) x 6
USB 3.0 (Type-B) x 1
Video:
HDMI input
Display Port input
VGA input
Display Port output
Audio:
12W+12W
(Internal Speaker)
3.5mm Stereo input
Headphone OUT output
Control:
RS-232C
input/output
USB:
USB 3.0 (TypeA) x 4
 Bottom access
USB 3.0 (TypeB)
Video:
HDMI input
Display Port input
VGA input
Display Port output
Audio:
8W+8W
(Internal Speaker)
3.5mm Stereo input
Speaker output
Control:
RS-232C
input/output
Manuals

Interactive Whiteboards Line-up
A series

Model name RICOH IWB A8600NEW RICOH IWB A7500NEW RICOH IWB A6500NEW
Size W1968 x H1173 x D88 (mm) W1723 x H1035 x D88 (mm) W1512 x H921 x D88 (mm)
Weight 73kg 51kg 39kg
Display Resolution 4K 4K 4K
Contrast
Ratio
1200:1 (typ.) 1200:1 (typ.) 1200:1 (typ.)
Touch 20 points 20 points 20 points
I/F
USB:
USB 2.0 (TypeA) x 1 Side access
USB 3.0 (TypeA) x 2 Side access
USB 3.0 (TypeA) x 2 Front access
USB 3.0 (TypeB) x 1 Side access
USB 3.0 (TypeB) x 1 Front access
USB Type-C x 1 Front access
Video:
HDMI input x 2 Side access
HDMI input x 1 Front access
Display Port input x 1 Side access
VGA input x 1 Bottom access
HDMI output x 1 Bottom access
Audio:
15W+15W (Internal Speaker)
3.5mm Stereo input x 1 Bottom access
Headphone OUT output x 1 Bottom access
Mic input x 1 Bottom access
SPDIF x 1 Bottom access
Control/Others:
RS-232C x 1 Bottom access
LAN x 2 Side access
USB:
USB 2.0 (TypeA) x 1 Side access
USB 3.0 (TypeA) x 2 Side access
USB 3.0 (TypeA) x 2 Front access
USB 3.0 (TypeB) x 1 Side access
USB 3.0 (TypeB) x 1 Front access
USB Type-C x 1 Front access
Video:
HDMI input x 2 Side access
HDMI input x 1 Front access
Display Port input x 1 Side access
VGA input x 1 Bottom access
HDMI output x 1 Bottom access
Audio:
15W+15W (Internal Speaker)
3.5mm Stereo input x 1 Bottom access
Headphone OUT output x 1 Bottom access
Mic input x 1 Bottom access
SPDIF x 1 Bottom access
Control/Others:
RS-232C x 1 Bottom access
LAN x 2 Side access
USB:
USB 2.0 (TypeA) x 1 Side access
USB 3.0 (TypeA) x 2 Side access
USB 3.0 (TypeA) x 2 Front access
USB 3.0 (TypeB) x 1 Side access
USB 3.0 (TypeB) x 1 Front access
USB Type-C x 1 Front access
Video:
HDMI input x 2 Side access
HDMI input x 1 Front access
Display Port input x 1 Side access
VGA input x 1 Bottom access
HDMI output x 1 Bottom access
Audio:
15W+15W (Internal Speaker)
3.5mm Stereo input x 1 Bottom access
Headphone OUT output x 1 Bottom access
Mic input x 1 Bottom access
SPDIF x 1 Bottom access
Control/Others:
RS-232C x 1 Bottom access
LAN x 2 Side access
Manuals

Controller Line-up

Model name RICOH Collaboration Board
Controller Type 3
RICOH Interactive Whiteboard
Controller OP-10
RICOH Interactive Whiteboard
Controller OP-5
RICOH Interactive Whiteboard
Controller OP-5 Type 2NEW
Compatible display RICOH Collaboration Board D series RICOH Interactive Whiteboard A series
OS Windows 10 IoT Windows 10 Professional Windows 10 Professional Windows 10 Professional
CPU IntelR Core i5-6500TE IntelR Core i7-6700TE IntelR Core i5-6500TE Intel Core i5-8259U
RAM 8GB 16GB 8GB 16GB
Strage 128GB 512GB 128GB 512GB
Network Wired LAN(10BASE-T/ 100BASE-TX/ 1000BASE-T) 10BASE-T/ 100BASE-TX/ 1000BASE-T
Wireless 802.11 ac/a/b/g/n 802.11 ac/a/b/g/n/ax
Bluetooth Bluetooth 4.1 embedded Embedded
I/F OPS
USB:
USB 3.0 (TypeA) x 3
Video:
HDMI output
Audio:
Line Out
Mic In
USB:
USB 3.0 (TypeA) x 2
USB 2.0 (TypeA) x 2
USB Type-C x 1
Video:
HDMI output x 1
Audio:
3.5 mm microphone jack x 1
3.5 mm headphone jack x 1
Capture
box parts*
Video:
HDMI input
Display Port input
VGA input
Manuals
Firmware/Software

* Capture box is bundled with Controller Type 3. But it's an option for Controller OP-5 and OP-10.

Solution Line-up

Solution RICOH Creative Collaboration for IWB RICOH IWB Add-on Service for Office 365
Controller RICOH IWB Controller OP-5
RICOH IWB Controller OP-5 Type 2
RICOH IWB Controller OP-10
RICOH Collaboration Board Controller Type 3
RICOH IWB Controller Type 2
Features & benefits
  • Welcome screen set for the meeting
  • Supported by all Microsoft Windows 10 applications and available in the app folder for a simple and safe activation
  • Wired, wireless and QR code content sharing directly from the laptop or smartphone
  • Powerful canvas to turn your notes into digital contents
  • Easy access to most of the video conferencing systems available on the market
  • Virtual assistant via pop-up or voice available to support the execution of the main activities and guarantee the best meeting experience
  • Simplify set up and make your meetings more engaging
  • Cloud-based Office 365 collaboration for RICOH IWB displays
  • Simple and secure badge/card ‘tap and go’ authentication
  • Initiate meetings directly from your Outlook calendar
  • Access the latest files directly from your OneDrive
  • Annotate, save and share content with meeting participants
